H380 Series 220V/380V Vector Frequency Inverter
Category：
Specification：
● 110VAC 1PH To 3PH 0.4~1.5KW
● 220VAC 1PH To 3PH 0.4~2.2KW
● 220VAC 1PH To 1PH 0.4~2.2KW
Skype：
Email：
Product Introduction
Specification：
● 110VAC 1PH To 3PH 0.4~1.5KW
● 220VAC 1PH To 3PH 0.4~2.2KW
● 220VAC 1PH To 1PH 0.4~2.2KW
● 220VAC 3PH To 3PH 0.4~2.2KW
● 380VAC 3PH To 3PH 0.75~7.5KW
● 220VAC 1PH To 380VAC 3PH 0.75~2.2KW
● DC TO AC Solar Pump Inverter
Single Phase 220V 80~400Vdc
Three Phase 380V 120~800Vdc
Product Features:
(1) V/F, Sensorless vector control;
(2) Performance meets the GB/T12668-2002, IEC61800 standard.
(3) Compact design with easy key operation
(4) Parameter auto-tuning function: static parameter auto-tuning function;
(5) Customized functions are available.( We support OEM & ODM)
(6) Customized functions are available.( We support OEM & ODM)
(7) Built-in PID&Standard RS485 communication;
(8) Protection mode: overcurrent protection, overvoltage protection, overheat protection and overload protection.
Productapplication:
Fans, water pumps and other equipment that need to track the speed, textile machinery, CNC machine tools, tissue machinery, printing and packaging machines, etc
| Model | Rated Power (KW) | Rated Current (A) |
outine Dimension(mm) | Package Dimension(mm) | GW(KG) |
| 220V1-phase input &3-phase output (Voltage Range:-15%220V~220V+15%) | |||||
| H380-0R4G-S2 | 0.4 | 2.5A | 85*143*116 | 230*160*170 | 1.3KG |
| H380-0R7G-S2 | 0.75 | 5.0A | |||
| H380-1R5G-S2 | 1.5 | 7.0A | |||
| H380-2R2G-S2 | 2.2 | 10A | 100*157*120 | 1.5KG | |
| 380V3-phase input &3-phase output (Voltage Range:-15%380V-380V+15%) | |||||
| H380-0R7G/R5P-T4 | 0.75 | 3.0A | 100*157*120 | 230*160*170 | 1.5KG |
| H380-1R5G/2R2P-T4 | 1.5 | 4.0A | |||
| H380-2R2G/4ROP-T4 | 2.2 | 5.0A | |||
| H380-4ROG/5R5P-T4 | 4.0 | 8.5A | 113*209*188 | 320*170*245 | 2.78KG |
| H380-5R5G/7R5P-T4 | 5.5 | 13A | 2.8KG | ||
| H380-7R5G/liRP-T4 | 7.5 | 18A | 2.82KG | ||
| 220V3-phase input &3-phase output (Voltage Range:-15%220V~220V+15%)%.220V-220V+15%) | |||||
| H380-0R4G-T2 | 0.4 | 2.5A | 100*157*120 | 230*160*170 | 1.5KG |
| H380-0R7G-T2 | 0.75 | 5.0A | |||
| H380-1R5G-T2 | 1.5 | 7.0A | |||
| H380-2R2G-T2 | 2.2 | 10A | |||
| 220V1-phase input &1-phase output (Voltage Range:-15% 220V~ 220V+15%) | |||||
| H380-0R4G-S1 | 0.4 | 2.5A | 85*143*116 | 230*160*170 | 1.3KG |
| H380-0R7G-S1 | 0.75 | 5.0A | |||
| H380-1R5G-S1 | 1.5 | 7.0A | |||
| H380-2R2G-S1 | 2.2 | 10A | 100*157*120 | 1.5KG | |
| 110V 1-phase input &3-phase output (Voltage Range:-15%110V~110V+15%) | |||||
| H380-0R4G-S2-110V | 0.4 | 2.5A | 85*143*116 | 230*160*770 | 1.3KG |
| H380-0R7G-52-110V | 0.75 | 5.0A | |||
| H380-1R5G-S2-110V | 1.5 | 7.0A | |||
| 220V1-phase input &380V3-phaseoutput (Voltage Range-15%220V-380V+15%) | |||||
| H380-0R7G-S4 | 0.75 | 5.0A | 100*157*120 | 230*160*170 | 1.5KG |
| H380-1R5G-S4 | 1.5 | 7.0A | |||
| H380-2R2G-S4 | 2.2 | 10A | |||
FMZ Parts ( EMI Filter & Reactor ) can work for below branded VFD (AC Drive, Frequency inverter, Variable frequency drive, VSD, Inverter)
ABB, SIEMENS, DANFOSS, VACON, SEW, LENZE, PETER ELECTRONIC, LEISTER, WATT DRIVE, KEB, BONFIGLIOLI, NORD, CAG ELECTRIC MACHINERY, INTECNO, SYCOTEC, KB ELECTRONICS, TDE MACNO SPA, GEFRAN, CONTROL TECHNIQUES, PEPPERL FUCHS, GRUNDFOS, VEM MOTORS, BR INDUSTRI-ELEKTRONIK, RK ROSE+KRIEGER, CARLO GAVAZZI, LEROY SOMER, VERLINDE, TRANSTECNO, STAHL CRANE SYSTEMS GMBH, MIYACHI, DEMAG CRANES COMPONENTS, ABM, ROSSI, COGNITO QUAM, GE, AIRTECNICS, Delta, Teco, Toshiba, Mitsubishi, fuji, Yaskawa, Hitachi, Omron, Panasonic, HYUNDAI, LS/LG.
Key Words / Main Products:
Frequency inverter, inverter, AC Drives, frequency converters, frequency changers, adjustable speed drives (ASD), adjustable frequency drives (AFD), variable frequency drives (VFD), variable speed drives (VSD), Soft Starters, Soft Stop, Soft Starters for AC Motor, Motor Starters, Motor Soft Starters, EMI filter, Input EMI Filters, Output EMI Filters, AC Choke, AC Reactor, Input AC Choke， Output AC Choke， Input AC Reactor, Output AC Reactor, DC Choke, DC Reactor, Input DC Choke, Output DC Reactor, Input DC Reactor, HMI, Human Machine Interface,PLC，Programmable Logic Controller, Servo Drive, Servo Motor, Servo Motor & Drive, Servo Motor & Drive System
